700c Electric Bike | Leitner Ultimate
700c Electric Bike | Leitner Ultimate

700c Electric Bike | Leitner Ultimate

Regular price
Sold out
Sale price
$1,499.00


Australia's no. 1 rated eBike brand on Leitner Electric Bikes Review

Estimated availability date September 2020

This epic electric bike features groundbreaking stealth design - you wouldn't even know it's electric! The Samsung battery is hidden away in the frame and cutting-edge components reduce the weight to an incredible 17 kg. Stay ahead of the pack - order yours today!

Shipping cost calculated at checkout.

Electric Bike Features

Packed with features the Leitner Ultimate electric bike transforms cycling into a glorious experience.

  • Weighs only 17 kg - Australia's best value electric bike in this weight class
  • Suits riders 5'7" (170 cm) and taller (guide only)
  • Integrated bike computer with speedometer and odometer
  • Estimated 35-80km range with pedal assist mode.
  • Includes $120 worth of extras: Mudguards, crank-guard, front & rear lights, stand, bell and some tools to help with assembly
  • 36 Volt 250 Watts motor, 10.5 Ah Samsung Lithium Battery Cells
  • Seat height measured from ground to top of seat: Minimum 88 cm, Maximum: 111 cm
  • Not sure which model is right for you? Read the quick guide.

Just The Right Amount Of Assistance

You hold the power at your fingertips on this sleek control panel - 5 levels of pedal assistance allow you to adjust the power to your needs. Climb hills with ease or cruise along at up to 25 km/h - the 250W motor will do the work for you. Feel like getting some exercise? Put the setting to low or switch the power off altogether if you feel like a real workout. Integrated speedometer and odometer.

Geniune Integrated Samsung Battery

The battery is the most precious part of any electric bike. Therefore it's important to use quality parts such as Samsung battery cells which last for years. The high energy-density Samsung Battery cells in this electric bike are light-weight and allow you to travel an estimated 35-80 km.

Arrive Safely At Your Destination

Stay in control with 180mm front and rear TEKTRO disc brakes and a safety feature which will shut the motor off while braking.

Arrive Clean - Every Time

This electric bike is a neat-freak so you don't have to be! Your beloved clothes are protected from dirt thanks to the crank-cover, front and rear mudguards.

7-Speed Shimano Gears

Thumb-controlled Shimano gears will give you extra pedal power when going uphill and higher pedal speed on the flat. Stay in control with the non-slip handle-grip. And the bell, well... it rings ;)

Front And Rear Lights

Be seen with an integrated front light powered by the main battery and an independently powered rear light.

Every Ride A Joy Ride

Ride for hours on this comfy seat and still feel fresh. The handle-grips are non-slip for maximum control and the adjustable handle-stem allows you to find your perfect riding position.

700c (28") Tires

Piece of mind with branded Kenda Kwest tires.

Easy To Charge

Charge the battery at any standard power socket with the included charger. No need to wait until the battery is empty. Charge it at any time. It takes about 5 hours for a full charge and less for a partial charge.

Electric Bike Dimensions
(cm)

Electric Bike

Detailed Electric Bike Technical Specifications | Click To Hide

Motor

Innovative light-weight rear wheel hub brushless geared motor AKM-13.0 by Aikema , 36V 250W, High Torque, whisper quiet during operation.

Frame

Aircraft-grade light-weight Aluminum Alloy 6061

Battery

36V 10.5Ah Lithium-ion battery with high energy-density ICR18650 genuine Samsung 35E battery cells. Located inside the down tube of the frame. Check battery charge on the handle-bar display. Charging port with dust cover located on the frame. Charge battery at any standard power outlet. The battery is designed to be charged while it's inside the frame of the bike.
The battery can be removed and replaced for warranty purposes, however it is NOT recommended to buy a spare battery and regularly remove and install batteries to avoid damage to the internal wiring.

Brakes

Mechanical disc brakes TEKTRO MD-M280 front and rear, with large 180mm rotor for improved stopping power. Tektro brake levers.

Control Panel

Sleek LCD display with 5 levels of pedal assist, odometer, speedometer, trip meter, light button (push and hold the up button for 3 seconds) and voltage display to estimate battery charge level.

Lights

Integrated front light powered by the main battery. Rear light powered by it's own battery.

Reflectors

Spoke mounted wheel reflectors (orange), pedal reflectors (orange)

Handle-stem

Can be tilted towards rider and away from rider using an allen key to achieve an upride riding position or forward-leaning riding position or anything in between.

Handle-bar

Straight. When closest to rider (upright): 103cm high, 57cm distance from centre of seat post. When furthest away from rider: 92cm high, 68 cm distance from centre of seat post.

Gears

7 speed SHIMANO Tourney gears with thumb shifter on right-hand side handle-bar. Shimano Cassette (Freewheel) 14-28 tooth MF-TZ500-7

Tires

Kenda Kwest 700 x 38c tires (28") - with inner tube 50-85psi (please refer to tire side wall)

Fork

Rigid front fork

Seat and Seatpost

Medium width comfort seat.

Cranks

52 tooth sprocket, Alloy, 170mm PROWHEEL with Pedal Assist Speed Sensor on left crank arm.

Pedals

Aluminium Alloy by Wellgo, non-foldable

Maximum Assisted Speed

25 km/h

Mudguards

Front and rear PVC mudguards, black color. Light-weight and rust-free, shape is resilient to impact

Weight

Bike weighs 17 kg

Carry capacity

Maximum payload of 120 kg. This includes rider and luggage.

Charger

2A 36V charger - connect to standard wall power socket. 5-6 hours charge time if battery completely empty. Quicker charge time if battery is not completely empty. Battery can be charged at any time - it does not have to be completely empty.

Content
Electric Bike
Battery
Charger
Manual
Tools to help with assembly
Online Assembly manual

Buy with confidence

Leitner Electric Bikes are covered by a 2 year warranty against manufacturer faults of the frame and with a 1 year warranty against manufacturer faults of the electric parts. Warranty terms apply.

Once you receive the bike, if you are not completely satisfied, you are more than welcome to return it to us within 14 days. The bike must not show any signs of usage, must be in original packing and the buyer is responsible for all shipping costs. Return terms apply.

Please make sure you read the manual carefully before use! Leitner invests large amounts of time and resources into service and continuous improvement. Leitner eBikes are sold factory direct, so you can be sure of quality and value.

Images for illustration only. Measurements approximate. Actual product may vary slightly.
