26" Dual Suspension Mountain Ebike | Leitner CrossX
26" Dual Suspension Mountain Ebike | Leitner CrossX
26" Dual Suspension Mountain Ebike | Leitner CrossX
26" Dual Suspension Mountain Ebike | Leitner CrossX

26" Dual Suspension Mountain Ebike | Leitner CrossX

Regular price
$1,569.00
Sale price
$1,545.00


Australia's no. 1 rated eBike brand on Leitner Electric Bikes Review

The Leitner CrossX is a great value Electric Mountain Bike with 26" wheels combining the comfort of a dual suspension frame with the bold look of a step-over shaped frame. Equipped with genuine Samsung battery cells and a powerful motor this eBike will make conquering mountains fun and easy.

FEATURES

Packed with features the CrossX will help you reach your destination in comfort and style.

  • No license required, top speed of 25 km/h
  • Up to 50km range with pedal assist mode. Up to 80km range with upgraded 16Ah battery (add $250)
  • Includes $150 worth of extras: Mudguards, front & rear lights, stand, bell and tool-kit to help with assembly
  • 36 Volt 250 Watts motor, Samsung Lithium Battery Cells
  • Suits riders 5'5" (165 cm) and taller (guide only)
  • Seat height measured from ground to top of seat: Minimum 84 cm, Maximum: 103 cm
  • Not sure which model is right for you? Read the quick guide.

Removable Samsung Battery - Convenient And Secure

The battery is the most precious part of any Ebike. Therefore it's important to use quality parts such as Samsung battery cells which last for years. Unlock the battery with your security keys and remove it in seconds thanks to the seat which folds up. Charge it wherever it suits you best and protect it from theft. You can also charge the battery while it's on the bike. Push the button on top to check the charge.

Extra Comfortable Dual Suspension

A smooth ride is guaranteed also in bumpy situations thanks to the additional frame suspension. In this price-range this is hard to beat.

Arrive Clean - Every Time

This bike is a neat-freak so you don't have to be! Your beloved clothes are protected from dirt thanks to the front and rear mudguards and a chain bash-guard

Don't Feel Like Pedaling? Use The Throttle!

Twist the throttle for help at take-off and you can cruise along at 6km/h (walking speed). The red button is an additional safety feature to switch the throttle off to prevent accidental activation. Riding on private property and not on public roads? Unlock the throttle to go 25km/h without pedaling. Instructions provided.

Just The Right Amount Of Assistance

You hold the power at your fingertips - 3 levels of pedal assistance allow you to adjust the power to your needs. Climb hills with ease or cruise along at up to 25 km/h - the 250W motor will do the work for you. Feel like getting some exercise? Put the setting to low or switch the power off altogether if you feel like a real workout.

Every Ride A Joy Ride

Ride for hours on this luxurious seat and still feel fresh. The front fork has suspension for a smooth ride also in bumpy situations. The handle-bars are straight and an adjustable handle-stem allows you to find your perfect riding position.

Easy To Charge

Charge the battery at any standard power socket with the included charger. No need to wait until the battery is empty. Charge it at any time. It takes about 5 hours for a full charge and less for a partial charge.

Arrive Safely At Your Destination

Stay safe in traffic with integrated front lights and battery powered rear lights and a full set of reflectors. Stay in control with front and rear TEKTRO disc brakes and a safety feature which will shut the motor off while braking.

Detailed Technical Specifications | Click To Hide

Motor

Rear wheel hub brushless geared motor by XOFO, 36V 250W. XOFO is Leitner's preferred motor supplier due to extremely high reliability outperforming Bafang motors in our experience. Leitner's partnership with XOFO goes back to 2013.

Frame

Aircraft-grade light-weight Aluminum Alloy 6061

Battery

Removable 36V 10Ah Lithium-ion battery with ICR18650 Samsung Battery Cells or upgrade to a 36V 16Ah battery Located behind seat post with lock and keys. Removable in seconds. Check battery charge by pushing the button on top of the battery.

Brakes

Mechanical disc brakes TEKTRO Aries front and rear, 160mm rotor

Control Panel

Kingmeter M790 LED display with 3 levels of pedal assist, switch for lights and voltage display to estimate battery charge level.

Lights

Integrated frontlights powered by the main battery, rear lights powered by AA battery.

Reflectors

front and rear reflectors, spoke mounted wheel reflectors (orange), pedal reflectors (orange)

Handle-stem

Can be adjusted and tilted towards rider and away from rider using an allen key to achieve an upride riding position or forward-leaning riding position or anything in between.

Handle-bar

Curved at ends towards rider

Gears

6 speed SHIMANO Tourney gears with thumb shifter on right-hand side handle-bar. Cassette (Freewheel) 14-28 tooth.

Tires

Kenda 26" tires, 1.95" wide - with inner tube and knobby mountain-bike profile

Fork

RST front suspension fork

Rack

No

Cranks

48 tooth sprocket, Alloy, 170mm PROWHEEL with Pedal Assist Speed Sensor

Pedals

Wellgo non-foldable

Maximum Assisted Speed

25 km/h

Mudguards

Front and rear PVC mudguards, black color. Light-weight and rust-free, shape is resilient to impact

Weight

Bike weighs ~25 kg with battery, ~ 22 kg without battery, battery weighs ~3 kg

Carry capacity

Maximum payload of 120 kg. This includes rider and luggage.

Charger

2A 36V charger - connect to standard wall power socket. 5-6 hours charge time if battery completely empty. Quicker charge time if battery is not completely empty. Battery can be charged at any time - it does not have to be completely empty.

Seat and Seatpost

Wide comfort seat by Velo. Seat-post folds up on demand to allow fast removal of battery.

Content
eBike
Battery
Charger
Manual
Tools to help with assembly
Assembly manual

Buy with confidence

Leitner Electric Bikes are covered by a 2 year warranty against manufacturer faults of the frame and with a 1 year warranty against manufacturer faults of the electric parts. Warranty terms apply.

Once you receive the bike, if you are not completely satisfied, you are more than welcome to return it to us within 14 days. The bike must not show any signs of usage, must be in original packing and the buyer is responsible for all shipping costs. Return terms apply.



Please make sure you read the manual carefully before use! Leitner invests large amounts of time and resources into service and continuous improvement. Leitner eBikes are sold factory direct, so you can be sure of quality and value.

Images for illustration only. Actual product may vary slightly.
